Rubber Timing Belt , type P2M , P3M , P5M , P8M , P14M
Quick Detail:
P2M, P3M, P5M, P8M, P14M Rubber Timing Belt
Rubber material
Standard and non-standard Timing Belt available
With high quality and competitive price
Prompt delivery
Package as per customer’s demand.
Description:
We are the leading top Chinese belt manufacturer, and are specializing in various high quality rubber timing belt
1. Material: Rubber.
2. OEM/ODM welcome
3. LOW noises, NO slippage
4. HIGH transmission power
5. Wear Out Resistance
6. Heat resistant, oil resistant
7. Rubber timing belt type: P2M, P3M, P5M, P8M, P14M
Applications:
Our rubber timing belt are used in Textile, Printing and Chemical Machine and Medical Equipment
Specification:
Our timing belt feature
1) It may solve the problems such as low transmission efficiency and lubrication oil required under the status of high speed when suing the chain, distance limit between the drive part and the slave drive part when using the gear.
2) Glass fiber as tensile member. No elongation of rubber belt.
3) Excellent heat-resistance, oil-proof, and wearing resistance
4) Higher transmission efficiency can be guaranteed under the condition of large change of speed and temperature.
5) Its performance can be exerted stably and safely during the process of high-speed rotation.
Size as below:
| Type | Type | Pitch | Tooth height | Belt thickess |
| HTD | 3M | 3 | 1.17 | 2.4 |
| 5M | 5 | 2.06 | 3.8 |
| 8M | 8 | 3.36 | 6 |
| 14M | 14 | 6.02 | 10 |
| 20M | 20 | 8.4 | 13.2 |
| STPD/STS | S2M | 2 | 0.76 | 1.36 |
| S3M | 3 | 1.14 | 1.9 |
| S4.5M | 4.5 | 1.71 | 2.81 |
| S5M | 5 | 1.91 | 3.4 |
| S8M | 8 | 3.05 | 5.3 |
| S14M | 14 | 5.3 | 10.2 |
| RPP/HPPD | Rpp2M | 2 | 0.76 | 1.36 |
| Rpp3M | 3 | 1.15 | 1.9 |
| Rpp5M | 5 | 1.95 | 3.5 |
| Rpp8M | 8 | 3.2 | 5.5 |
| Rpp14M | 14 | 6 | 10 |
Technique parameter:
| Type | Pich Length | Teeth Number |
| 112-P2M | 112 | 56 |
| 120-P2M | 120 | 60 |
| 132-P2M | 132 | 66 |
| 180-P2M | 180 | 90 |
| 184-P2M | 184 | 92 |
| 236-P2M | 236 | 118 |
| 250-P2M | 250 | 125 |
| 266-P2M | 266 | 133 |
| 274-P2M | 274 | 137 |
| 280-P2M | 280 | 140 |
| 310-P2M | 310 | 155 |
| 328-P2M | 328 | 164 |
| 426-P2M | 426 | 213 |
| 448-P2M | 448 | 224 |
| 530-P2M | 530 | 265 |
| 560-P2M | 560 | 280 |
| 710-P2M | 710 | 355 |
| 984-P2M | 984 | 492 |
| 1066-P2M | 1066 | 533 |
| 1224-P2M | 1224 | 612 |
Technique parameter:
| Type | Pich Length | Teeth Number | Type | Pich Length | Teeth Number | Type | Pich Length | Teeth Number |
| 105-P3M | 105 | 35 | 288-P3M | 288 | 96 | 513-P3M | 513 | 171 |
| 129-P3M | 129 | 43 | 291-P3M | 291 | 97 | 522-P3M | 522 | 174 |
| 141-P3M | 141 | 47 | 297-P3M | 297 | 99 | 525-P3M | 525 | 175 |
| 144-P3M | 144 | 48 | 300-P3M | 300 | 100 | 531-P3M | 531 | 177 |
| 147-P3M | 147 | 49 | 318-P3M | 318 | 106 | 537-P3M | 537 | 179 |
| 150-P3M | 150 | 50 | 327-P3M | 327 | 109 | 564-P3M | 564 | 188 |
| 159-P3M | 159 | 53 | 330-P3M | 330 | 110 | 570-P3M | 570 | 190 |
| 168-P3M | 168 | 56 | 333-P3M | 333 | 111 | 576-P3M | 576 | 192 |
| 174-P3M | 174 | 58 | 336-P3M | 336 | 112 | 579-P3M | 579 | 193 |
| 177-P3M | 177 | 59 | 339-P3M | 339 | 113 | 597-P3M | 597 | 199 |
| 180-P3M | 180 | 60 | 345-P3M | 345 | 115 | 600-P3M | 600 | 200 |
| 186-P3M | 186 | 62 | 354-P3M | 354 | 118 | 621-P3M | 621 | 207 |
| 195-P3M | 195 | 65 | 357-P3M | 357 | 119 | 621-P3M | 621 | 211 |
| 201-P3M | 201 | 67 | 363-P3M | 363 | 121 | 621-P3M | 621 | 216 |
| 204-P3M | 204 | 68 | 375-P3M | 375 | 125 | 669-P3M | 669 | 223 |
| 210-P3M | 210 | 70 | 384-P3M | 384 | 128 | 711-P3M | 711 | 237 |
| 213-P3M | 213 | 71 | 390-P3M | 390 | 130 | 735-P3M | 735 | 245 |
| 225-P3M | 225 | 75 | 393-P3M | 393 | 131 | 756-P3M | 756 | 252 |
| 231-P3M | 231 | 77 | 405-P3M | 405 | 135 | 804-P3M | 804 | 268 |
| 240-P3M | 240 | 80 | 420-P3M | 420 | 140 | 882-P3M | 882 | 294 |
| 243-P3M | 243 | 81 | 432-P3M | 432 | 144 | 945-P3M | 945 | 315 |
| 246-P3M | 246 | 82 | 447-P3M | 447 | 149 | 1062-P3M | 1062 | 354 |
| 252-P3M | 252 | 84 | 474-P3M | 474 | 158 | 1125-P3M | 1125 | 375 |
| 255-P3M | 255 | 85 | 480-P3M | 480 | 160 | 1245-P3M | 1245 | 415 |
| 264-P3M | 264 | 88 | 486-P3M | 486 | 162 | 1263-P3M | 1263 | 421 |
| 267-P3M | 267 | 89 | 489-P3M | 489 | 163 | 1500-P3M | 1500 | 500 |
| 270-P3M | 270 | 90 | 501-P3M | 501 | 167 | 1530-P3M | 1530 | 510 |
| 276-P3M | 276 | 92 | 510-P3M | 510 | 170 | 1863-P3M | 1863 | 621 |
Technique parameter:
| Type | Pich Length | Teeth Number | Type | Pich Length | Teeth Number | Type | Pich Length | Teeth Number |
| 180-P5M | 180 | 36 | 500-P5M | 500 | 100 | 890-P5M | 890 | 178 |
| 225-P5M | 225 | 45 | 525-P5M | 525 | 105 | 935-P5M | 935 | 187 |
| 235-P5M | 235 | 47 | 535-P5M | 535 | 107 | 940-P5M | 940 | 188 |
| 245-P5M | 245 | 49 | 550-P5M | 550 | 110 | 950-P5M | 950 | 190 |
| 255-P5M | 255 | 51 | 565-P5M | 565 | 113 | 980-P5M | 980 | 196 |
| 265-P5M | 265 | 53 | 575-P5M | 575 | 115 | 1000-P5M | 1000 | 200 |
| 270-P5M | 270 | 54 | 580-P5M | 580 | 116 | 1050-P5M | 1050 | 210 |
| 285-P5M | 285 | 57 | 600-P5M | 600 | 120 | 1100-P5M | 1100 | 220 |
| 298-P5M | 298 | 59.6 | 610-P5M | 610 | 122 | 1125-P5M | 1125 | 225 |
| 300-P5M | 300 | 60 | 635-P5M | 635 | 127 | 1195-P5M | 1195 | 239 |
| 305-P5M | 305 | 61 | 640-P5M | 640 | 128 | 1200-P5M | 1200 | 240 |
| 325-P5M | 325 | 65 | 670-P5M | 670 | 134 | 1240-P5M | 1240 | 248 |
| 345-P5M | 345 | 69 | 675-P5M | 675 | 135 | 1270-P5M | 1270 | 254 |
| 350-P5M | 350 | 70 | 700-P5M | 700 | 140 | 1420-P5M | 1420 | 284 |
| 375-P5M | 375 | 75 | 705-P5M | 705 | 141 | 1595-P5M | 1595 | 319 |
| 400-P5M | 400 | 80 | 710-P5M | 710 | 142 | 1690-P5M | 1690 | 338 |
| 420-P5M | 420 | 84 | 725-P5M | 725 | 145 | 1790-P5M | 1790 | 358 |
| 425-P5M | 425 | 85 | 740-P5M | 740 | 148 | 1800-P5M | 1800 | 360 |
| 450-P5M | 450 | 90 | 755-P5M | 755 | 151 | 1895-P5M | 1895 | 379 |
| 455-P5M | 455 | 91 | 780-P5M | 780 | 156 | 2000-P5M | 2000 | 400 |
| 460-P5M | 460 | 92 | 800-P5M | 800 | 160 | 2250-P5M | 2250 | 450 |
| 465-P5M | 465 | 93 | 835-P5M | 835 | 167 | 3500-P5M | 3500 | 700 |
| 475-P5M | 475 | 95 | 850-P5M | 850 | 170 | | | |
Technique parameter:
| Type | Pich Length | Teeth Number |
| 966-P14M | 966 | 69 |
| 1190-P14M | 1190 | 85 |
| 1400-P14M | 1400 | 100 |
| 1610-P14M | 1610 | 115 |
| 1764-P14M | 1764 | 126 |
| 1778-P14M | 1778 | 127 |
| 1890-P14M | 1890 | 135 |
| 2100-P14M | 2100 | 150 |
| 2310-P14M | 2310 | 165 |
| 2450-P14M | 2450 | 175 |
| 2590-P14M | 2590 | 185 |
| 2800-P14M | 2800 | 200 |
| 3150-P14M | 3150 | 225 |
| 3360-P14M | 3360 | 240 |
| 3500-P14M | 3500 | 250 |
| 3850-P14M | 3850 | 275 |
| 4326-P14M | 4326 | 309 |
| 4578-P14M | 4578 | 327 |
| 4956-P14M | 4956 | 354 |
timing belt, mitsuboshi timing belt, megadyne timing belt, bando timing belt, chery timing belt, timing belt china, pu timing belt, industrial timing belt, timing belt kit, double sided timing belt, rubber timing belt, gt2 timing belt, rpp5m rubber timing belt, dayco timing belt, peugeot timing belt, industrial timing belts china, htd timing belt, car timing belt, open ended timing belt, mxl timing belt, auto timing belt, gates timing belt, cnc timing belt, t5 timing belt, timing belt s2m, timing belt for printer, automotive timing belt, transmission timing belts, pu endless timing belt, industrial rubber timing belts, htd 5m timing belt, polyurethane timing belts, mxl rubber timing belt, timing belt s8m, china timing belt, s5m timing belts, t2.5 timing belt, timing belt for printing machine, endless timing belt, t20 timing belt, engine timing belt, s3m timing belt, xl timing belt, 3m timing belt, double timing belts, double tooth timing belt, t10 timing belt, 117my21 timing belt, toothed timing belt, t type timing belt, open timing belt, timing belt xl, std timing belt, rpp8m timing belt, at20 timing belt, car engine timing belt, 5m timing belt, pu open timing belt, ribbed timing belt, open end pu timing belt, synchronous timing belts, rubber auto timing belt, pu open ended timing belt, double-sided timing belt, conveyor timing belt, high quality timing belt, pu steel cord timing belt
Competitive Advantage:
More than 20 years advanced technology and experience of us will give strong support for the timing belt you need. We will understand your need of product quickly, and give quick respond and good service. A lot of cases of our products will show you that it worth your trust.
Under the full quality control system, our products go through the precise product line and strict testing process. We have excellent working flow and standard to ensure stability, products reliable enough for using.
Take our scale economy, raw material superiority, and sincerity for clients to account, our price has a great competitiveness. They are good value and cost effective than your imagine.
We sincerely hope establishing long and friendly business relations with clients from all over the world. Our goal is not just providing product, but also providing a complete solution including product design, tooling, fabrication and service for our customers to achieve their upmost satisfaction.
