    Conveyor Mill Machine Industrial Worm Gearbox Reducer

    Ask Lasest Price
    Brand Name : MW
    Model Number : OTHER
    Price : USD50-100/PCS
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 100000PCS/MONTH
    Delivery Time : 20-40DAYS
    • Product Details
    • Company Profile

    Conveyor Mill Machine Industrial Worm Gearbox Reducer

    Industrial Customized Helical Tiller Worm Gearbox Reduction For Conveyor Mill Machine
    Our Gearbox has many items for your choosing and we can produce as per your drawing or sample to meet your special request
    1. Large output torque
    2. Safe, reliable, economical and durable
    3. Stable transmission, quiet operation
    4. High carrying ability
    5. High modularization design, may equip with various outer power input conveniently. Same machine type may equip with various power motor. It is easy to realize the combination and junction between every machine type
    6. Transmission ratio: Fine division, wide scope. The combined machine type may form very large transmission ratio, i. E. Output very low rotary speed.
    7. Form of installation: The position to be installed is not limited.
    8. High strength, compact the box body of high strength cast iron, gear and gear shaft adapts the gas carbonization, quenching and fine grinding process, therefore the bearing capacity of unit volume is high.
    9. Long life: Under the condition of correct type chosen(including choosing suitable operation parament ) normal operation and maintenance, the life if main parts speed reducer(except wearing parts)should not be less than 20000 hours. The wearing parts include lubricating oil, oil seal and bearing.
    10. Low noise: Because main parts of speed reducer are processed, and tested critically, therefore the noise of speed reducer is low.
    11. Our gear box have reached the advance international level, can replace the same kind of products imported.

    Conveyor Mill Machine Industrial Worm Gearbox ReducerConveyor Mill Machine Industrial Worm Gearbox Reducer

    Item No.
    HC-7241
    Ratio
    3:1
    Teeth
    10/30
    Module
    5.0
    HP
    30
    Rated Input
    540rpm
    Input/Output Description
    Hexagon Spline
    Optic Axis
    Net Weight
    18.5kg

    Conveyor Mill Machine Industrial Worm Gearbox ReducerConveyor Mill Machine Industrial Worm Gearbox Reducer

    Item No.
    HC-7251
    Ratio
    3.18:1
    Teeth
    11/35
    Mould
    5.08
    HP
    40
    Rated Input
    540rpm
    Input/Output Description
    Optic Axis
    Optic Axis
    Net Weight
    27.5kg

    Conveyor Mill Machine Industrial Worm Gearbox ReducerConveyor Mill Machine Industrial Worm Gearbox Reducer

    Item No.
    HC-09030-1
    HC-09030-2
    HC-09030-3
    Ratio
    1:1.93
    1:1.47
    1:1.69
    Teeth
    15/29
    15/22
    13/22
    Module
    4.0
    5.08
    5.0
    HP
    30
    40
    35
    Rated Input
    540rpm
    540rpm
    540rpm
    Input/Output Description
    Hexagon Spline(1 3/8 Z6)
    Optic Axis
    Cone base aequlate spline shaft
    Net Weight
    26.5kg
    26.5kg
    26.5kg

    Conveyor Mill Machine Industrial Worm Gearbox ReducerConveyor Mill Machine Industrial Worm Gearbox Reducer

    Item No.
    HC-09031-1
    HC-09031-2
    HC-09031-3
    Ratio
    1:1.93
    1:1.47
    1:1.69
    Teeth
    15/29
    15/22
    13/22
    Module
    4.0
    5.08
    5.0
    HP
    30
    40
    35
    Rated Input
    540rpm
    540rpm
    540rpm
    Input/Output Description
    Hexagon Spline ( 1 3/8 Z6 )
    Cone base aequlate spline shaft
    Net Weight
    24.5kg
    24.5kg
    24.5kg

    Conveyor Mill Machine Industrial Worm Gearbox ReducerConveyor Mill Machine Industrial Worm Gearbox Reducer

    Item No.
    HC-09033-1
    HC-09033-2
    Ratio
    1:1.93
    1:1.47
    Teeth
    15/29
    15/22
    Module
    4.0
    5.08
    HP
    30
    40
    Rated Input
    540rpm
    540rpm
    Input/Output Description
    Hexagon Spline(1 3/8 Z6)
    Optic Axis
    Cone base aequlate spline shaft
    Net Weight
    25.5kg
    25.5kg

    Conveyor Mill Machine Industrial Worm Gearbox ReducerConveyor Mill Machine Industrial Worm Gearbox Reducer

    Item No.
    HC-09061-1
    HC-09061-2
    Ratio
    1:1.92
    1:1.47
    Teeth
    14/27
    13/19
    Module
    5.5
    7.0
    HP
    60
    60
    Rated Input
    540rpm
    540rpm
    Input/Output Description
    Hexagon Spline ( 1 3/8 Z6 )
    Cone base aequlate spline shaft
    Net Weight
    37kg
    37kg

    Conveyor Mill Machine Industrial Worm Gearbox ReducerConveyor Mill Machine Industrial Worm Gearbox Reducer

    Item No.
    HC-09081-1
    HC-09081-2
    Ratio
    1:1.92
    1:1.47
    Teeth
    14/27
    13/19
    Module
    5.5
    7.0
    HP
    60
    60
    Rated Input
    540rpm
    540rpm
    Input/Output Description
    Hexagon Spline ( 1 3/8 Z6 )
    Cone base aequlate spline shaft
    Net Weight
    43kg
    43kg

    Conveyor Mill Machine Industrial Worm Gearbox ReducerConveyor Mill Machine Industrial Worm Gearbox ReducerConveyor Mill Machine Industrial Worm Gearbox Reducer

    Item No.
    PK.005
    Ratio
    2.05:1
    Teeth
    17/25
    Module
    4.5
    Rated Input
    540rpm
    Input/Output Description
    Optic Axis
    Optic Axis
    Net Weight
    31kg

    Conveyor Mill Machine Industrial Worm Gearbox Reducer

    Conveyor Mill Machine Industrial Worm Gearbox Reducer

    Hangzhou Ocean Industry Co., Ltd. is a specialized supplier of a full range of chains, sprockets, gears, gear racks, v belt pulley, timing pulley, V-belts, couplings, machined parts and so on.

    Due to our sincerity in offering best service to our clients, understanding of your needs and overriding sense of responsibility toward filling ordering requirements, we have obtained the trust of buyers worldwide. Having accumulated precious experience in cooperating with foreign customers, our products are selling well in the American, European, South American and Asian markets. Our products are manufactured by modern computerized machinery and equipment. Meanwhile, our products are manufactured according to high quality standards, and complying with the international advanced standard criteria.

    With many years' experience in this line, we will be trusted by our advantages in competitive price, one-time delivery, prompt response, on-hand engineering support and good after-sales services.

    Additionally, all our production procedures are in compliance with ISO9001 standards. We also can design and make non-standard products to meet customers' special requirements. Quality and credit are the bases that make a corporation alive. We will provide best services and high quality products with all sincerity. If you need any information or samples, please contact us and you will have our soon reply.
    FAQ:
    Q1: Are you trading company or manufacturer ?
    A: We are factory.

    Q2: How long is your delivery time and shipment?
    1.Sample Lead-times: generally 10 workdays.
    2.Production Lead-times: 20-40 workdays after getting your deposit.

    Q3. What is your terms of payment?
    A: T/T 30% as deposit, and 70% before delivery.

    Q4: What is your advantages?
    1. Manufacturer,the most competitive price and good quality.
    2. Perfect technical engineers give you the best support.
    3. OEM is available.
    4. Rich stock and quick delivery.

    Q5. If you can’t find the product on our website,what do you next?
    Please send us inquiry with product pictures and drawings by email or other ways and we'll check.
